200MM RUBBER WHEEL 250KG CAPACITY SWIVEL CASTOR (S8040)

$81.00 inc. GST

Order in

SKU: 101152040 Category: Brand:

Features:

  • The S8040 manufactured by Richmond Wheel and Castor Co. is a swivel frame castor and has a rubber wheel.
  • This swivel castor is one of their 300 series plate range and can hold loads up to 250kg.
  • The S8040 uses roller bearings for wheel rotation and is mounted with the baseplate.
  • The swivel frame design of this castor permits the load to be steered.
  • The rubber wheel diameter is 200mm, the wheel width is 50mm and you can order separately (Part Number: RT8842).
  • To order this castor with a brake, search for S8040B.

Dimensions & Specifications:

Product Code S8040
Wheel Diameter (mm) 200
Frame Type Swivel
Wheel Width (mm) 50
Wheel Type Rubber
Wheel Code RT8842
Wheel Bearing Type Roller Bearing
Castor Height (mm) 237
Swivel Radius (mm) 156
Maximum Load Capacity (kg) 250
Recommended Load Capacity (kg) 225
Diameter

200MM

Size

WLL 250KG

UOM

EACH

MPN 075THES8040
Barcode 9331244024158
