TOLEDO DIAL INDICATOR ANALOGUE 0.001 X 1MM

Features:

• High precision expert dial gauges for precision measuring work
• Dial face with O-ring and internal housing sealing ensures unit is waterproof and dustproof
• Shock-proof mechanism prevents damage to the internal gears if the spindle is pushed abruptly
• Hardened SK quenched steel stem with specialty fastening to eliminate failure
• Superior quality spindle rack, pinions and gear trains ensure longevity
• Easy read design incorporates white dial face with black graduations and pointer needle
• Knurled Bezel provides a firm and secure grip
• Securely fitted back cover with four locking screws enables lug to rotate at 90° angles
• Manufactured to JIS B 7503
• Made in Japan

Specifications:

■ Type: Metric
■ Graduation Range: 0.001 x 1mm
■ Reading: 0 – 100 – 0
■ Indication Error:
1/10 Revolution – 2μm
1/2 Revolution – ±2μm
One Revolution – ±3μm
Two Revolution – ±13μm
Full Measuring Range – ±3μm
■ Retrace Error: 2μm
■ Repeatability: 0.5μm
■ Measuring Force: < 1.5N
