PUDDLE SUCKER PUMP 170 L/MIN 11M HEAD

$528.00 inc. GST

Order in

Local Pickup Only
This product cannot be shipped and must be collected from our store.
SKU: 101201868 Category: Brand:

The ClayTech PSP530 is a manually operated, light duty, occasional use pump suitable for pumping mostly clean water with minimum soft solids or other contamination.

The PSP530 is a ‘puddle sucker’ type pump. Once primed and pumping, it will pump down to depths less than 3mm making it ideal for basement, garage or pool drainage applications.

Features
  • Pump can be primed through discharge outlet for startup at any water level. The Internal check valve holds prime and restricts back flow through pump when stopped.
  • Quality pump materials and construction to ensure reliable operation
  • Industrial grade coating
  • 10m H07RN-F Neoprene power lead and float lead
  • Easy to install and use
Benefits
  • Light weight – easy to lift and lower
  • Compact and able to be employed in sumps where space is limited
Technical Data
RATED POWER (W) 530W
MAX. FLOW [LPM] 170 lpm
MAX. HEAD [M] 11m
WORKING TEMPERATURE < 40°C
LIQUID TEMPERATURE 3°C – 40°C
MAX. IMMERSION DEPTH 10m
MAX. DIA. OF PARTICLE < 2mm
MOTOR DUTY S1 Continuous
MOTOR PROTECTION LEVEL Class B
MOTOR PROTECTION In-built auto re-setting thermal overload
CAPACITOR 10 uF +/-5% 450V
MOTOR SHAFT Stainless Steel 201
RATED VOLTAGE 220V-240V 50 Hz
RATED CURRENT 2.0A @ 230V
POWER CABLE TYPE 10m H07RN-F
PROTECTION CLASS IPX8
IMPELLERS Single Impeller
HYDRAULIC BODY Coated AISi12
INLET STRAINER No
OUTLET 1” DN hose tail
MECHANICAL SEALS Graphite/Ceramic
AUTOMATION FUNCTION N/A – Manual Operation
NET WEIGHT (KG) Pump only 13.5kg
PACKAGE DIMENSION 220Lx220Wx340H (mm)
Weight 13.00 kg
UOM

EACH
MPN 810679
