M18™ FORCE LOGIC™ 137KN INLINE UTILITY CRIMPER (TOOL ONLY)

The M18™ FORCE LOGIC™ 137kN Inline Utility Crimper makes crimping easy. The battery-powered crimper’s unique in-line design and centre-balanced grip allows you to use it with one hand, reducing peak muscle effort. Featuring a Quick Release with Push-to-Close pin design that provides easy access around splices and joins, and a 350° rotating head ensures quick alignment on the job. The crimper is fully compatible with all industry-standard P-Dies and P-to-U Die Adapters, allowing you to utilize existing dies and can complete crimps up 750mm2 CU and 630mm2 AL when using P-Dies. Predictive Force Monitoring (PFM™) constantly measures force output to provide you with the fastest crimp speed while delivering accurate pressure with instant verification every time. The M18™ FORCE LOGIC™ 137kN Inline Utility Crimper can deliver up to 90 crimps on a single 5.0Ah battery and features a POWERSTATE™ Brushless Motor matched with REDLINK™ Electronics providing unmatched reliability in the toughest conditions.

Features:

• Crimps up to 750mm2 CU & 630mm2 AL (using 15T P-Dies).
• Up to 90 crimps per charge using a 5.0Ah battery on 1000 MCM AI.
• 350° Rotating head with Quick Release/Push to Close Jaw design.
• Compatible with “P” Dies and “P to U” Die adapters.
• One handed grip for easy alignment.
• One Key™ Enabled.

Specifications:

• PLATFORM: M18™ / ONE-KEY™
• CAPACITY: 630mm² (1250 MCM) Cu / 750mm² (1500 MCM) Al
• ONE-KEY ENABLED: Yes
• LENGTH: 591 mm
• WEIGHT: 7 kg
• WARRANTY: 5 Years
• CRIMPING FORCE: 137kN
• CRIMP TIME: 8.5 Seconds (1000 MCM AI)
• PREDICTIVE FORCE MONITORING (PFM™): Yes
