CHAIN HOIST, ELECTRIC, 240V, 1T, 6M LIFT, TOHO

$2,604.00 inc. GST

Order in

Local Pickup Only
This product cannot be shipped and must be collected from our store.

SKU: 100076831 Category: Electric Hoists Brand: TOHO

Description
Additional information

Japanese Technology
Load Limited
Thermal Overload Prevention
Lightweight, compact design with a high-efficiency motor
Pressed steel structure, high strength body
High tensile alloy steel top & bottom hooks
Grade 80 – 7.1mm Alloy Steel load chain
Limit switches fitted at top and bottom ends to prevent chain runout
240V, 50Hz Single Speed Motor 1200 Watts.
Complies with ASNZS1418.2 standard

*Hoists can be re-chained to your required length (limits apply)

Specifications

Capacity: 1 ton
Standard Lift: 6 m
Running Test Load: 12.5 kN
Motor Power: 1.2 kW
No. of Chain: 1
Diameter of Chain: 7.1 mm
Lifting Speed: 6 m/min
Extra Weight per metre of extra lift: 1.1 kg

Weight	63.00 kg
Length	6M
Size	WLL 1T
UOM	EACH
MPN	TECH0106
Barcode	9343662004698
