CANTILEVER GATE GUIDE WHEEL (GTR031)

Features:

• Suits GTR025 140mm wide cantilever gate channel.
• Richmond cantilever gate guide wheels are clamped in the ends of the gate channel.
• The guide wheel protrudes from the bottom of the channel and will roll smoothly into the Cantilever Gate End Catch (Sold Separately).
• Zinc Plated to protect from rust, our cantilever gate guide wheels feature a heavy gauge steel construction and high-quality wheels.

Dimensions & Specifications:

• A: 195mm
• B: 140mm
• C: 140mm
• D: 98mm
• E: 95mm
• F: 24mm
