75MM CI WHEEL 100KG CAPACITY SWIVEL CASTOR (S3306)
$20.80 inc. GST
Order in
The S3306 manufactured by Richmond is a swivel frame castor and uses a cast iron wheel. This swivel castor is one of our light industrial series range and has a maximum capacity of 125kg. The S3306 wheel is fitted with plain bearings. This castors swivel frame allows the castor to swivel 360°. The diameter of the cast iron wheel is 75mm, the wheel width is 32mm and you can order separately (Part Number: Ci3340).
Specifications:
| Product Code | S3306 |
|---|---|
| Wheel Diameter (mm) | 75 |
| Frame Type | Swivel |
| Wheel Width (mm) | 32 |
| Wheel Type | Cast Iron |
| Wheel Bearing Type | Plain Bore |
| Castor Height (mm) | 108 |
| Swivel Radius (mm) | 71 |
| Maximum Load Capacity (kg) | 100 |
| Temperature range (°C) | -20° to 280° |
| Diameter | 75MM |
|---|---|
| Size | WLL 100KG |
| UOM | EACH |
| MPN | 064LINS3306 |
| Barcode | 9331244011721 |
